PRODUCT INFORMATION (Plank Specifications – Warranties) Construction Type: High Performance Flooring Grade: Simulated A-B Grade (includes simulated knots and mineral streaks) Color Choice: Refer to Johnson’s product information sheet Wear-Layer Thickness: N/A Overall Thickness: 13.5 mm (12.0 mm Core + 1.5 mm IXPE Foam Pad) Core Material 12.0 mm WaterShield High Core Width: 7 5/8” (Nominal) Length: 23.5”, 47”, 71” (Nominal) Bevel: Painted Micro Bevel Click System: Valinge 5G Dry Underlayment: 1.5 mm IXPE Foam (Water Resistant) Style: Registered Embossing (EIR), FloorScore Certified and Greenguard Gold Certified Finish: AC5 Rated Luster: Low Gloss Color Tone/Variation: Medium INSTALLATION: Floating (On, Above, Below) Subfloor: Refer to Guidelines PACKAGING: SQ/FT Per Carton: 22.6 Cartons Per Pallet: 55 SQ FT/PLT: 1,243.00 PCS Per Carton: Random Pounds Per Carton: 52 PERFORMANCE: TEST METHOD RESULTS Acoustical Performance ASTM E90-09, ASTM E492-09 STC-53 and IIC-53 (For additional testing data please contact Johnson’s Technical Department @ 800-910-3047). NOTE: Our Bella Vista Series is Water Resistant (but not waterproof), Scratch Resistant (but not scratchproof), Stain Resistant (but not stainproof) and Ultra Durable. WARRANTIES: Limited 80 Hour Topical Moisture Warranty, Limited 20-Year Light to Medium Commercial Warranty, Limited Lifetime residential Warranty.
